Technical Feature:

1. Lumbar and cervical integration traction, can use by two patients in the same time.

2. Traction force auto compensation, synchronal detecting set value and actual traction force.

3. 8 kinds of traction mode, can store, read 20 curing parameter medical records.

4. Easy traction parameter enters function.

5. Various safety design (patient emergency switch, doctor emergency switch)

6. Firstly adopts seconds as intermittent time unit, much more practical.

7. The counter traction function of our company is the first registered and passed in Food and drug administration in China

Technical parameters：

Supply：220V/50Hz

Power：300VA

Lumbar traction parameters：

Traction force：0～99kg (adjustable)

Length：0～200mm

Total traction time：0～99min (adjustable)

Traction time：0～9min (adjustable)

Intermittent time：0～90s (adjustable)

YHZ-100BⅠ：≤100mm

Cervical traction parameters：

Traction force：0～30kg (adjustable)

Length：0～300mm

Total traction time：0～99min (adjustable)

Traction time：0～9min (adjustable)

Intermittent time：0～90s (adjustable)

Product Size(L*W*H)：2450×600×720mm

Packing Size (wooden cases 1pc/case)：2580×680×780mm

(N.W)：115kg
(G.W)：140kg
